Sale Bruker MATRIX-F FT-NIR Spectrometer USED
BRUKER
MATRIX-F FT-NIR Spectrometer The award winning MATRIX-F is the next generation of FT-NIR spectrometers for process applications. Accurate in-line results in seconds Multiple components per measurement Non-destructive analysis Built-in 6-port multiplexer The award winning MATRIX-F is a dedicated Fourier Transform Near Infrared (FT-NIR) process spectrometer. It is the first industry hardened FT-NIR system that can directly withstand harsh environments.
$3,299.00
Bruker BRUKER MATRIX-F FT-NIR Spectrometer USED
MATRIX-F FT-NIR Spectrometer The award winning MATRIX-F is the next generation of FT-NIR spectrometers for process applications. Accurate in-line results in seconds Multiple components per measurement Non-destructive analysis Built-in 6-port multiplexer The award winning MATRIX-F is a dedicated Fourier Transform Near Infrared (FT-NIR) process spectrometer. It is the first industry hardened FT-NIR system that can directly withstand harsh environments.
MATRIX-F is an ideal process instrument, which can also be installed as a stand-alone system for method development in the laboratory, and then moved directly into your process application.
MATRIX-F is available as a free-standing unit with NEMA 4/IP66 (splash proof) housing. It can also be mounted in a standard 19-inch rack in a temperature-controlled cabinet. MATRIX-F can be equipped with a 6-port fibre optic multiplexer.
Specifications :
Detection Category
Chemical; Explosives
Detection Principle
Molecular Spectroscopy;
Detection Method
Near Infrared
Application
Laboratory Analysis
Equipment Type
Instrument
Product Synopsis
MATRIX-F is a compact near-IR spectrometer designed for quality assurance/process control using optical fibers. The spectrometer module is equipped with an internal 2-port fiber optic multi-plexer and can be updated to 6 measurement positions.
Availability
Commercially Available
Technology Readiness Level (TRL)
9
User Feedback Sources
Indifferent/No user feedback
Dimensions
12.6 x 16.5 x 7.9in (32 x 42 x 20cm)
Weight
>50 Lbs.; 52 lbs. (24kg)
Power Requirements
AC/DC Line Power
Noise Produced
Negligible
Transportability
Benchtop/Fixed
Ruggedness
Indoor use only
Operating Conditions
5 to 35° (41 to 95°F)
Solvents/Reagents
None
Data Analysis Support Equipment
OPUS software
Communications Interface
Ethernet
Expected Operational Life
Indefinite
Shelf Life
>5 years
Tested For Chemical Agents
Amenable based on technology
Tested For ITF-25 TIC/TIMs
Amenable based on technology
Tested For Explosives
Amenable based on technology
Tested For Narcotics
Amenable based on technology
Tested For Biological Agents
Not Applicable
Other Biological Targets
Not Applicable
Radiological Targets
Not Applicable
Number of Library Entries
Multiple libraries available
Adaptability
Yes; user can add new targets in the field
Sample Introduction
Solid; Liquid
Sensitivity/Detection Limits
ppm; Bulk; mg
Known Interferents/Inhibitors
Fluorescence
Response Time (Sample Application To Output)
<5 minutes
Alarm Capability
None
Software Control
PC
Other Operational Parameters
Resolution 2 cm-1; spectral range 12,800 - 4,000 cm-1; Class 1 laser
Training Required
<1 week training
Training Available
In-person, videos
Manuals Available
Operator's manual
Reachback Service
Yes
Warranties
Yes
Also you can check product : Sale Bruker S1 Titan 600 Handheld XRF Analyzer USED
- Availability: 16 In Stock
- Model: MATRIX-F
-
Brand:
