Sale Waygate Technologies XL Detect Borescopes USED

Waygate Technologies XL Detect Borescopes USED

The XL Detect and XL Detect+ VideoProbes provide unmatched imagequality and powerful light output to boost probability of detection (POD) and speed up workflow. Rugged durability lowers your maintenance costs and expert support from Waygate Technologies gives you peace of mind. All in a lightweight, portable, and easy-to-use device. Now featuring 16GB of memory and an upgraded 5” LCD screen on the XL Detect+.

Get accurate results, fast.
Complete efficient, precise inspections with unmatched image quality, plus a 5” LCD screen on the XL Detect+.

Cut down on costs.
Lower your maintenance spending with durability you can trust, even in the harshest inspection environments.

Stay flexible.
At just 4.3 lbs., the device is lightweight and portable, with a wheeled carry-on case for easy transport.

Learn quickly.
The intuitive interface includes Menu Directed Inspection (MDI) 2.0, an application to guide users through inspections and organize results for simpler reporting.

Experience true peace of mind.
Get readily available assistance from Waygate Technologies experts, wherever you are.

Now with a 5” LCD screen for clear-cut inspections.
The new XL Detect+ display is 85% larger and 3X brighter, with crystal clear image quality unmatched in the industry. Paired with advanced optics and powerful light output, that means sharper images right on your device. Because when you can see clearly, you improve POD, speed up your workflow, and deliver results with confidence.

Believe it when you see it
Reduce eyestrain with powerful light output and a 3x brighter display in the XL Detect +

Specifications :

Tip operating temp
-25°C to 100°C (-13°F to 212°F) Reduced
articulation below 0°C (32°F)

System operating temp
-20°C to 46°C (-4°F to 115°F) LCD requires
warm-up period below 0°C (32°F)

Storage temperature
-25°C to 60°C (-13°F to 140°F)

Relative humidity
95% max, non-condensing

Waterproof
Insertion tube and tip to 14.7 psi (1 bar, 10.2
m of H2 O, 33.5 ft of H2 O)

System

Wheeled case
54.9 x 34.6 x 23.6cm (21.61 x 13.62 x 9.29in)

System weight
In case:
XL Detect: 6.50 kg (14.30 lb)
XL Detect+: 8.39 kg (18.5 lb)

Without case:
XL Detect: 1.73 kg (3.8 lb)
XL Detect+: 1.98 kg (4.37 lb)

Power (Lithium Ion battery)
8.4 V, 38 Wh (2 hour) 8.4 V, 75 Wh (4 hour)

Power supply
AC Input: 100-240 VAC, 50-60 Hz, 1.5 A Max
DC Output: 9.5 V, 6.0 A

Construction
Polycarbonate housings with integrated Versalon (JP) bumpers

Dimensions
XL Detect: 9.53 x 13.34 x 34.29 cm (3.75 x 5.25 x 13.50 in)
XL Detect+: 10.2 x 16.5 x 34.3 cm (4.0 x 6.5 x 13.5”)

LCD monitor:
XL Detect: Integrated transflective 9.40 cm (3.70 in) active matrix VGA color LCD with
XpertBright, 640 x 480 resolution
XL Detect+: Integrated 12.7 cm (5.0) active matrix
VGA color LCD, Transmissive display.

Joystick control
360° All-Way tip articulation with XpertSteer, bump gesture, menu access
and navigation

Button set
Access user functions, measurement and digital functions

Audio
Integrated 2.5 mm headset/microphone jack

Internal memory
XL Detect: 4 GB Flash memory
XL Detect+: 16 GB Flash memory

Data I/O ports
Two USB 2.0 ports

Video port
VGA Video Out

Brightness control
Auto and Variable

Illumination type
White LED

Long exposure
Via auto and manual mode

White balance
Factory default or user defined

Standards compliance and classifications

MIL-STD-810G
Tested to United States Department of Defense Environment Tests Sections 506.5,
507.5, 509.5, 510.5, 511.5, 514.6, 516.6, 521.3

MIL-STD-461F XL Detect
Tested to United States Department of Defense Electromagnetic
Interference RS103 - ABOVE DECK

Standards compliance
Group 1, Class A: EN61326-1 UL, IEC, EN CSA-C22.2:61010-1 UN/DOT T1-T8

IP rating
XL Detect: Tested to IP55
XL Detect+: Tested to IP64

Camera

4.0 mm (0.157 in) diameter probes

Image sensor
1/10 inch Color SUPER HAD CCD camera

Pixel count
290,000 pixels

Housing
Titanium

Software

Operating system
Real-time multi-tasking operating system

User interface
Simple drop-down menu-driven operation Menu navigation using articulation joystick

File manager: Embedded file manager software supporting
File & Folder creation, naming, deleting Store to internal Flash (C:\) or USB
ThumbDrive Copy between USB and C:\

MDI software (optional)
Provides user defined guided inspection Creates DICONDE compatible inspection
files Creates MS Word® compatible inspection reports

Audio data
PC compatible (.AAC) file format

Image control
Invert, Zoom (5X digital) Image Capture and Recall

Digital zoom
Continuous (5.0X)

Image formats
Bitmap (.BMP), JPEG (.JPG)

Video format
MPEG 4

Text annotation: Built-in full screen text overlay generator
Supports international language character sets 100 text line capacity

Graphic annotation
User placement of arrows

Articulation control
“Steer & Stay” articulation lock/fine
articulation Tip “Home” return to neutral forward-tip orientation Userselectable fine or coarse control XpertSteer probe articulation offers quick steering
responsiveness for tight probe control-bump steering enables slight adjustments to probe position

Software updates
Field updateable via USB ThumbDrive

Languages
English, Spanish, French, German, Italian, Russian, Japanese, Korean, Portuguese, Chinese, Polish

INCLUDED :

(1) 6.1mm (50° FOV, 1.97in to infinity DOF)
(1) 3.0m (9.8ft) Insertion Tube Working Length
(1) 2-hour Li-Ion Battery
(1) Backpack Case
(1) AC Adapter/Battery Charger
(1) Documentation Thumbdrive
(1) Quickstart Card
(1) Inspection Manager

Also you can check product : Sale Waygate Technologies Everest XLG3 VideoProbe USED

• Availability: 15 In Stock
• Model: XL Detect
• SKU: XLDPB61
• Brand:
