Sale GeoSLAM Zeb Revo 3D Laser Scanner USED

GeoSLAM Zeb Revo 3D Laser Scanner USED

The ZEB-REVO Solution GeoSLAM.com ”Go-anywhere” 3D mobile mapping technology. Handheld, lightweight and easy to use scanners that allow you to rapidly build highly accurate 3D models within minutes, while on the move. The complete solution that allows you to start mapping the world around you today.

Lightweight, handheld laser scanners which are highly mobile, simple to operate and can be used by anyone. Our versatile technology is adaptable to any environment, especially complex and enclosed spaces, without the need for GNSS. The 100Hz surveying system includes scanner, data logger and accessories and enables you to accurately scan and capture data, while on the move

User-friendly desktop software which turns data into real-time 3D information, delivering rapid and accurate results within minutes. With unlimited point cloud processing software and local registration, you can check your survey data instantly on site and export files in a range of industry standard formats.

Support & maintenance options depending on what your business needs – including helpdesk, issue analysis and resolution, product enhancement and release management.

Data capture with the ZEB_REVO is as simple as ‘walk and scan’. Map a 3-storey building in just 30 minutes to an accuracy level of ±15mm or scan, view and export up to 10,000 m2 in under 1 hour. Join our customers as they measure building plans 10 times faster than traditional tools, deliver BIM models earlier than expected and experience project cost savings of up to two thirds. And with this solution, customers can expand their range and scope of services by taking on projects that would otherwise have proved too difficult or time consuming using traditional survey techniques.

GeoSLAM ZEB-REVO Solution

Our customers are more profitable, more efficient and more competitive with our 3D mobile mapping solutions. Here are the benefits you can experience by choosing the ZEB-REVO solution:

”Go-anywhere” 3D mobile mapping – our versatile technology is adaptable to any environment in all industries, especially complex and enclosed spaces, without the need for GNSS. Flexible mounts and deployment options means the ZEB-REVO can be handheld, drone or robot mounted or even attached to a pole or cable. Weighing only 3.5kg, the handheld device can be used to quickly scan multi-level environments, and with an IP64 rating, it can withstand hazardous and harsh environments.

Rapid scanning time – within minutes anyone can be operating the ZEB-REVO, and our intelligent software (which uses the most established and robust SLAM mapping algorithm in the industry) can map a 3-storey building in just 30 minutes to an accuracy level of ±15mm, or map a 10,000 m2 (105,000 sq. ft.) depot in under an hour. Walk through your target survey environment to record more than 43,000 measurement pts/sec, and from scan to full 3D BIM model in under an hour!

Saving you time and money – you can capture and model complex data up to 10 times faster, enabling you to successfully complete projects in minimum time with little or no disruption at the project site. With proven ability to scan faster than traditional surveys or static terrestrial laser scanning, you can reduce scanning time, in many cases by half. Customers often find that the ZEB-REVO is highly complementary to their existing scanning hardware, as the combination allows indoor handheld scanning to take place at the same time as the outdoor scanning, saving project time and money.

Specifications :

Maximum Range
30m*

Data Acquisition Rate
43,200 points/sec

Resolution
0.625° horizontal, 1.8° vertical

Angular FOV
270° x 360°

Supply Voltage
2VDC ± 10%

Supply Current
Max 1.5A, normal 1.0A

Power Consumption
Less than 20W

OperatingTemperature
0° to +50°

Operating Humidity
<85% RH

Mounting Operation
Removable handle provided, can also be pole or vehicle mounted

Data Storage Capacity
55GB

Raw data file size
-10MB for every 1 min scanning

Processed data file size
-8MB for every 1 min scanning

Default output file format
Multiple formats including .LAS, PLY and .e57

Compatibility
GeoSLAM data is compatible with all major CAD software packages

Relative Accuracy
1 – 3cm

Absolute Position Accuracy
3 – 30cm (10 mins scanning, 1 loop)

Laser Safety Class
Class 1 Eye Safe

Laser Wavelength
905nm

Scanner Line Speed
100Hz

Scanner Resolution
0.625° horizontal

Rotation Speed
0.5Hz

Battery Type
Lithium Polymer (LiPo)

Capacity
8Ah +/- 5%

Nominal Voltage
12V

Battery Life
4 hours (continuous use)

Charge Time
8 – 12 hours

Battery Lifespan
300+ cycles

Chargers Supplied
UK, USA, EU & AUS

Weight
600g

IP Rating
P64 (dust-tight, splashproof

Cable Connectors
LEMO multi pin

Weight (scanner)
1.0kg

Weight (total system)
4.1kG

Dimensions (scanner)
86 x 113 x 287mm

Dimensions (backpack)
220 x 180 x 470mm

INCLUDED :
GeoSLAM ZEB-REVO 3D Portable Scanner
GeoSLAM ZEB-DL2600 Data Logger
8GB Pen Drive
Mains Cable
USB Cable
LowPro Flipside 200 Backpack
Quick Start Guide
User Manual
Backpack
